Adixen ASM GRAPH - Page 183

D 100
T able of preventive maintenance intervals
ASM
102
S
ASM
122 D
ASM
142
ASM
142
S
ASM
142 D
ASM
Graph D+
ASM
182
T
ASM
192
T
ASM
192 T2
ASM
182 TD+
ASM
192 TD+
ASM
192 T2D+
ASM
1002
ASI
22
10000 h
(1)
Replacement of membranes and
replacement of valves.
CS
•
Primary pump maintenance/
replacement of membranes and
valves.
CS
•
12000 h
(1)
Regrease the molecular pump.
E 740
•
•
• • • •
•
•
Regrease the turbomolecular
pump.
E 740
•
•
•
•
•
•
Regrease the ATP 100 or
ATH 164 pump.
E 730
•
•
•
Regrease the AMP 007I molecular
pump.
CS
•
•
•
•
15000 h
(1)
Replace the ball bearings of the
ATH 31 pump.
CS
•
16000 h
(1)
or
2 years
(3)
Recalibration/exchange of the
internal calibrated leak or
calibrated leak
used for
calibration.
E 570
•
•
•
•
•
•
•
•
•
•
•
Complete service of the rotary
vane pump.
CS
•
•
•
•
•
•
22000 h
(1)
or 1 year
(3)
Replace the ball bearings and the
seals of the molecular pump and
turbomolecular pump.
E 740
•
•
•
•
•
Replace the ball bearings and the
seal of the ATP 100 or ATH 164
pump.
E 730
•
•
•
Complete maintenance of dr y
pump (ACP 28 pump/ACP 15
pump).
CS
•
•
•
24000 h
(1)
or 1 year
(3)
Replace the ball bearings and the
seals of the molecular pump.
CS
•
•
•
•
•
•
500000
cycles
Change the valves.
E 530
•
•
•
•
•
•
•
•
•
•
•
•
•
Every 2
years
Change ATH 31 pump ball
bearings if the leak detector has
not been used.
•
GB 02469 -
Edition
03 -
June
08
Frequency* Maintenance operations to be performed
CS : Please contact Customer Service
*Service intervals: The service intervals given are for applications and work rates which conform to the normal operating
conditions. If the
machine is operating under more difficult conditions they can be shortened.
(1) running time
(2) running time or storage
(3) storage
