Adixen ASM GRAPH - Page 245

To Next Page

To Previous Page

F 100

Tools

ASM 142

Alcatel Vacuum Technology France - User's Manual ASM 142

TRM DB02 03/2009

Ref

Descriptio n

P/N

Qty

Remarks

A024

CENTERING RING SS/PER DN25KF

068189

A025

FUNNEL

067592

A026

VACUUM GREASE (TUBE OF 10 G)

105290

A027

VACUUM SILICON GREASE (100 G BOX)

064600

A028 MOLD FOR LEAD SEAL

072427

A029

HOUSING KIT INSERTABLE - ATH20/30/40

A030

CELL, ANALYZER ; PACKAGING

A031

TEST CHAMBER ADAPTER; DN40KF

067791

A032

CYCLE COMMAND FOOT PEDAL

100913

A034

DETECTOR/TOUCH SCREEN PANEL SERIAL CABLE

A461946

A035

DETECTOR PACKAGING - 142

A038

CONVERTER- ACT 200T

101932

A039

CABLE CONVERTER - ACT 200T

A457415-025

* Contact customer services
