Alcatel Vacuum Technology France - User's Manual ASM 142

TRM DB02 03/2009

F 800

Pipes - Connections - Seals

ASM 142

Ref

Descriptio n

P/N

Qty

Remarks

H098

CLAMP, TUBE PRESS; 35.0/38.5 MM

107645

H099

CLAMP, TUBE PRESS; 12.8/15.0 MM

107648

H105

SEALS KIT, PERBUNAN - AMP007I

H113

MALE CONNECTOR 4/6 MM - 1/8 BSPT

083391

H114 FEMALE CONNECTOR 1/8 BSPT - LDS TUBE

067843

H115

O'RING DN16KF NBR

079237

H117

CENTERING RING DN16KF

068222

H124

O'RING 5.33 x 113,67 NBR

082152

H125

MALE PURGE FITTING (BHU 22-06 CPC)

107641

H132

I/O CONNECTOR STOPPER - 142

A459046

* Contact customer services
