Alcatel Vacuum Technology France - User's Manual ASM 142

TRM DB02 03/2009

F 1000

Options and accessories

ASM 142

Ref

Descriptio n

P/N

Qty

Remarks

J042

SNIFFER CANA.10 S S45 NIPPLE PENCIL

SNC2E4T1

J076

SNIFFER FILTER STONE

067722

* Contact customer services
