Figure 3: GNSS Compass alignment
3. Plug the cable into the GNSS Compass and rotate the nut clockwise to lock it in place. See GNSS Compass
connector locking
Figure 4: GNSS Compass connector locking
v2.0 Page 5 04 Nov 2021
GNSS Compass Reference Manual • Getting Started with GNSS Compass
