-IO Expansion Board Ensemble Epaq Hardware Manual

PIN-9

AUXSIN-

PIN-4

AUXSIN+

PIN-1

AUXMRK-

PIN-6

AUXMRK+

PIN-3

AUXCOS-

PIN-2

180

+5V

ADM1485

ENCODER

FAULT

DETECTION

ADM1485

AUXCOS+

Figure 3-14: Auxiliary Encoder Channel

www.aerotech.com Chapter 3 71
