Stopping the System
To stop the system:
1. Stop the NX workstation.
For a proper shutdown of the system, the NX workstation must be
shutdown first.
a) Go to the Main Menu.
b) Click the Exit NX action button.
c) In the MUSICA Acquisition Workstation Control Center, select Stop
NX.
To open the menu, go to the Windows taskbar and click the MUSICA
Acquisition Workstation Control Center.
Stopping the NX software also triggers the shutdown of the DR 800
sync cabinet.
d) In Windows, perform a shutdown of the PC.
2. In a configuration with a wireless DR detector, power off the DR detector:
• turn off the DR Detector.
• remove the battery pack.
3. Switch off the electrical room switch.
WARNING:
If the system has just been stopped, wait at least 10 seconds
before starting it again.
DR 800 | Basic Workflow | 141
0392C EN 20210309 1049
