Additional labeling of the radiographic table
Figure 36: Sample of type label
Type label of the radiographic table is on
the lower left side of the central table
frame.
Warning symbol that indicates that fingers
may be crushed.
Warning for maximum load on the table, as
specified in the technical data of the radio-
graphic table.
Release the compressor.
This mark indicates that this is a Type B
Equipment
Related Links
Radiographic table on page 290
