AGFA DR 800 - Ceiling Suspension; Positioning the X-ray tube of the ceiling suspension

Ceiling Suspension
1
2
3
4
5
6
1.
Transversal rails
2.
Carriage
3.
Longitudinal rails
4.
Telescopic column
5.
X-ray tube head unit
6.
Collimator
Figure 33: Ceiling Suspension
Topics:
• Positioning the X-ray tube of the ceiling suspension
• Collimator of the ceiling suspension
