AGFA DR 800 - Generator controls for static image, rapid sequence or DSA

Generator controls for static image, rapid sequence or
DSA
1
5
6
7
2
3
4
1.
Imaging mode
2.
Patient age group
3.
Radiographic working mode
4.
Sensor area
5.
Radiographic parameters
6.
Automatic exposure control
7.
Maximum rapid sequence time
Figure 154: Generator controls (example for rapid sequence)
To change a value, use the + and - buttons. The values increase or decrease
step by step each time the corresponding button is pushed. To change a value
without repeatedly pushing the buttons, push the value twice. The buttons
change into arrow up and arrow down buttons. Push and hold the button to
change the value.
After exposure all values reflect the settings actually used by the generator.
Topics:
• Radiography imaging modes
• Patient age group
• One point, two point and three point working modes
