Mounting the lower limbs support, ankle support or
head contention device
The lower limbs support device consists of two separate elements.
To mount the lower limbs support:
1. Place the tabletop in the horizontal position.
2. Loosen the knob of the lower limbs support.
3. Insert the lower limbs support on the tabletop guide.
4. Fasten the lower limbs support by turning the knob thoroughly clockwise.
1.
Inserting the lower limbs support
2.
Fastening the lower limbs support
Mounting of ankle support and head contention device are done in the same
manner as for the lower limbs support.
250 | DR 800 | Options and accessories
0392C EN 20210309 1049
