M Indication that manual corrections have been applied to the align-
ment of the partial images.
G Indication that automatic stitching has been performed based on the
stitching grid.
A Indication that automatic stitching has been performed based on the
alignment of the anatomical information in the image.
Y Indication that patient movement is detected.
N Indication that no patient movement is detected.
Figure 135: Example of a text annotation containing stitching parameters
3. Prepare the image for diagnosis by using e.g. L/R markers or annotations.
4. If the image is OK, send the image to a hardcopy printer and/or PACS
(Picture Archiving and Communication System).
