208 Agilent 1260 Infinity DAD and MWD User Manual
10 Maintenance
Maintenance of High Pressure Flow Cell
1
Use a 4 mm hex key to unscrew the window assembly [1]
and remove the gasket [2] from the cell body.
If you want to replace the gasket only, continue with step 8,
“Maintenance of Standard, Semi-Micro or Micro Flow
Cell” on page 203.
2 Use a tooth pick to remove the quartz window from the
window assembly.
3 Follow the procedure “Maintenance of Standard, Semi-Micro or Micro Flow Cell” on page 203 for reassembling.
&
'
&
'
&
'
(
)
*
,
-
'
