Agilent 1260 Infinity DAD and MWD User Manual 213
Maintenance
10
Replacing Capillaries on a Standard Flow Cell
13
Fix the heat exchanger to the clamp unit and the flow cell
body to the heat exchanger..
14 Fix the inlet capillary to the flow cell body handtight first.
Then do a 1/4 turn with a 4-mm wrench.
15 Check for a centered holder vs. hole. If required adjust
with the holder screws.
Next Steps:
16 Reconnect the capillaries, see “Exchanging a Flow
Cell” on page 200.
17 Perform a leak test.
18 Insert the flow cell.
19 Replace the front cover.
20 Perform a “Wavelength Verification and Recalibration” on
page 183 or a “Holmium Oxide Test” on page 174 to check
the correct positioning of the flow cell.
