© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-85
Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2000)
NOTE
Option #05A is not available on the Corporate
Price List (CPL) after June 1999. The DUT
power supplies input voltage for Japanese systems
are set to 220 volts at the factory and the neutral
center tap is no longer used.
If 3-phase Delta power (0ED) is not available, use
the Single-Phase power option (AWY). 307X
single-phase option AWY systems will require
two power drops.
1. Calculated with a fully-loaded 3X7X system with 3 STC cards in every module.
2. DUT Power supplies are configured for 200-240 volts ac.
3. Calculated with 6 STC cards in the module.
4. POTS and xDSL bays always require a separate power drop. Use the POTS/xDSL power options that is on the same line as the system power option.
5. Values in brackets [ ] apply to Series 3 systems with serial numbers less than those listed in
Table 10-6 on page 10-79.
