How to Use the Message Available Bit (MAV)
You can use the status byte “message available” bit (bit 4) to determine
when data becomes available to read into your bus controller. The meter
sets bit 4 when the first reading trigger occurs (which can be
TRIGger:SOURce:IMMediate). The meter subsequently clears bit 4
only after all messages have been read from the output buffer.
The message available (
MAV) bit can only indicate when the first reading
is available following a READ? command. This can be helpful if you do not
know when a trigger event such as BUS or EXTernal will occur.
The
MAV bit is set only after all specified measurements have completed
when using the INITiate command followed by FETCh?. Readings are
placed in the meter’s internal memory when using INITiate. Sending
the FETCh? command transfers readings (stored in internal memory
by the INITiate command) to the meter’s output buffer. Therefore, the
MAV bit can only be set after all measurements have been completed.
Using *OPC to Signal When Data is in the Output Buffer
Generally, it is best to use the “operation complete” bit (bit 0) in the
standard event register to signal when a command sequence is
completed. This bit is set in the register after an *OPC command has been
executed. If you send *OPC after a command which loads a message in
the meter’s output buffer (either reading data or query data), you can use
the operation complete bit to determine when the message is available.
However, if too many messages are generated before the *OPC command
executes (sequentially), the output buffer will fill and the meter will stop
taking readings.
Chapter 4 Remote Interface Reference
The SCPI Status Model
164
