Front-Panel Menu Reference
A: MEASurement MENU
1: DIG FILTER Ø 2: INTEGRATE Ø 3: OCOMP Ω Ø 4: LOW POWER Ω Ø 5: LOW VOLT Ω Ø 6: LoV LIMIT Ω
1: DIG FILTER Selects the digital filter speed. Can be set to FAST, MEDIUM, or SLOW.
2: INTEGRATE Sets the measurement integration time.
3: OCOMP Ω Enables or disables offset compensation for resistance measurements.
4: LOW POWER Ω Enables or disables low power ohms measurements.
5: LOW VOLT Ω Enables or disables voltage limited resistance measurements.
6: LoV LIMIT Ω Sets the voltage limit for voltage limited resistance measurements.
B: TEMPerature MENU
1:PROBE TYPE Ø 2: UNITS Ø 3: RTD TYPE Ø 4:RTD Ro Ø 5:T/C TYPE Ø 6: COLD JUNCT Ø 7:JUNCT TEMP
1: PROBE TYPE Selects thermocouples, thermistors, or RTDs as the temperature probe.
2: UNITS Sets the measurement units to either °C, °F, or Kelvins.
3: RTD TYPE Sets the type of RTD in use.
4: RTD Ro Sets the nominal (0°C) value for the RTD in use.
5: T/C TYPE Selects the type of thermocouple in use.
6: COLD JUNCT Sets the source of the temperature reference junction.
7: JUNCT TEMP Allows direct entry of reference junction temperature.
C: MATH MENU
1: STATS Ø 2: NULL VALUE Ø 3: SCALE GAIN Ø 4 : SCALE OFST
1:STATS Recalls the values of minimum, maximum, standard deviation, average,
peak-to-peak, and number of readings.
2: NULL VALUE Selects independent null settings for voltage on channels 1 and 2, resistance,
and temperature functions.
3: SCALE GAIN Sets the gain for linear scaling of the data.
4: SCALE OFST Sets the offset for linear scaling of data.
D: TRIGger MENU
1: READ HOLD Ø 2: TRIG DELAY Ø 3: N SAMPLES
1: READ HOLD Selects the reading hold sensitivity band.
2: TRIG DELAY Specifies a time delay between the trigger and the start of the measurement.
3: N SAMPLES Sets the number of samples taken per trigger.
2
Chapter 2 Front-Panel Operation
Front-Panel Menu Reference
31
