To Set the HP-IB Address
Each device on the HP-IB (IEEE-488) interface must have a unique
address. You can set the meter’s address to any value between 0 and 31.
The address is set to “22” when the meter is shipped from the factory.
The address is displayed on the front panel when you turn on the meter.
On/Off
Shift < 1 Turn on the front-panel menu.
A: MEAS MENU
< < 2 Move across to the I/O MENU choice on this level.
F: I/O MENU
∨ 3 Move down a level to the HP-IB ADDR command.
1: HP-IB ADDR
∨ 4 Move down to the “parameter” level to set the address.
Use the left/right and down/up arrow keys to change the address.
∧22 ADDR
Auto/Man 5 Save the change and turn off the menu.
ENTER The address is stored in non-volatile memory, and does not change when
power has been off or after a remote interface reset.
Chapter 4 Remote Interface Reference
To Set the GPIB Address
188
