To Select an Input Channel
For voltage measurements, you have two independent input channels.
• Pressing
Channel toggles the display between Channel 1 and
Channel 2.
• Pressing
Shift Channel (Scan) creates an alternating Channel 1 and
Channel 2 display. Press
Channel again to cancel.
Scan mode alternates between input channels every 3 seconds or every
measurement, whichever is longer. If you are using the scan mode, turn
off all the input filters (both digital and analog), see page 55.
RED
DC Voltage
BLACK
GREEN
DC Voltage
WHITE
TOGGLES MEASUREMENT CHANNEL
(SCAN) ALTERNATING MEASUREMENT CHANNELS
Channel 2
Channel 1
2
Chapter 2 Front-Panel Operation
To Select an Input Channel
41
