To Measure Temperature With Thermocouples
Thermocouple types: B, E, J, K, N, R, S, T
Reference: external thermistor, external fixed value, or internal thermistor.
Channel 2 only.
When using the internal thermistor as the temperature reference, you
should make a custom cable to connect the thermocouple wire directly
to the input terminals (see page 272).
ISOTHERMAL BLOCK
RED
REFERENCE
CH1 BLACK THERMISTOR
GREEN
CH2
WHITE
EXTERNAL
RED
CH1 OPEN
BLACK
GREEN
CH2
WHITE
ICE BATH
FIXED VALUE
OR
INTERNAL
CH2
OR
Chapter 1 Quick Start
To Measure Temperature With Thermocouples
22
