Bit Definitions — Operational Status Register
Bit Decimal Value Definition
0 Not Used Always set to 0
1
↓↓
↓
7
8 Filter Settled 256 Digital filter is settled.
9 Not Used Always set to 0.
↓↓ ↓
15
The operational status event register is cleared when:
• You execute a *CLS (clear status) command.
• You query the event register using STATus:OPERation:EVENt?.
The operational status enable register is cleared when:
• You turn on the power (*PSC does not apply).
• You execute the STATus:PRESet command.
• You execute the STATus:OPERation:ENABle 0 command.
Chapter 4 Remote Interface Reference
The SCPI Status Model
170
