Messages Displayed During Menu Use
TOP OF MENU -You pressed
∧ while on the menus level; this is
the top level of the menu and you cannot go any higher.
To turn off the menu, press
Shift <
(Menu On/Off). To move across
the choices on a level, press
<
or
>
. To move down a level, press
∨ .
MENUS - You are on the menus level. Press
< or > view the choices.
COMMANDS - You are on the commands level. Press
< or > to view
the command choices within the selected menu group.
PARAMETER - You are on the parameter level. Press
< or > to view
and edit the parameter for the selected command.
MENU BOTTOM - You pressed
∨ while on the parameter level; this is
the bottom level of the menu and you cannot go any lower.
To turn off the menu, press
Shift <
(Menu On/Off). To move up a level,
press
∧ .
ENTERED - The change made on the parameter level is saved. This is
displayed after you press
Auto/Man (Menu Enter) to execute the command.
MIN VALUE - The value you specified on the parameter level is too small for the
selected command. The minimum value allowed is displayed for you to edit.
MAX VALUE - The value you specified on the parameter level is too large for the
selected command. The maximum value allowed is displayed for you to edit.
EXITING - You will see this message if you turn off the menu by
pressing
Auto/Man (Menu On/Off) or a front-panel function/math key. You
did not edit any values on the parameter level and changes were NOT saved.
NOT ENTERED - You will see this message if you turn off the menu by
pressing
Shift < (Menu On/Off) or a front-panel function/math key.
You did some editing of parameters but the changes were NOT saved.
Press
Auto/Man (Menu Enter) to save changes made on the parameter
level.
VOLTS ONLY - The requested function is only available for voltage
measurements.
UNAVAILABLE - The action requested is NOT allowed in the present configuration.
Chapter 2 Front-Panel Operation
A Front-Panel Menu Tutorial
34
