3-32 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Connecting to Network
If You Use a Windows PC
Step 4. TCP/IP Properties
1. Click Properties to open the TCP/IP Properties dialog box. See Figure 3-14.
2. If the computer is installed with multiple network adapters, select one to use.
3. If you are going to use the DHCP server, click “Obtain an IP address from a
DHCP server”. You do not need to set the network parameters.
Otherwise, click “Specify an IP address” and set the network parameters.
4. Click OK.
5. Click OK.
6. Restart the computer.
Step 5. Network Connection Check
1. Log on to Windows.
2. Click Start, Programs, and Command Prompt to open the Command Prompt
window.
3. Ping a computer or a device on the network. If, for example, the IP address of
the device is 192.168.1.99, execute C:\> ping 192.168.1.99.
If any error occurs, perform these instructions again.
Figure 3-14 Setting up TCP/IP Properties
IP Address Tab
Example:
192.168. 1. 1
255.255.255. 0
192.168. 1. 3
TCP/IP Properties
Specify IP address
Obtain from DHCP
IP Address
Subnet Mask
Gateway
Adapter
OK
xx Adapter
2
3
4
Network
TCP/IP Protocol
OK
xxxx
xxxx
1
Properties
5
To Next Page
