Agilent 6500 Series Q-TOF LC/MS Maintenance Guide 143
Maintenance 2
To add rough pump fluid
7 Reconnect the power cord(s).
8 Start up the instrument.
See “To start the system in Standby mode” on page 15.
Figure 77 Rough pump.
Oil mist filter
Exhaust hose
Foreline hose
Oil return line
Ballast valve
Oil drain plug
Oil level sight glass
Oil drip pan
