146 Agilent 6500 Series Q-TOF LC/MS Maintenance Guide
2Maintenance
To replace the fuses
To replace the fuses
When required As needed.
Tools required Flat Blade Screw Driver
Parts required • 8 Amp Fuse 2110-0969
• 12.5 Amp Fuse 2110-1398
1 Unplug the instrument power cord(s) from the power outlet.
Figure 78 Disconnect the instrument power cable.
2 Using a flat blade screw driver, remove the fuse holder of the blown fuse.
Never replace a fuse with the instrument plugged into the power outlet, or you will
run the risk of an electric shock.
