Agilent 6500 Series Q-TOF LC/MS Maintenance Guide 109
Maintenance 2
To change HPLC-Chip capillaries
To change HPLC-Chip capillaries
When When broken, blocked or kinked
Tools Required • Cube wrench (p/n G4240-83800)
• Hex key 3 mm, 12-cm long (p/n 8710-2411)
Parts List • Fused silica/PEEK capillary (see Parts)
1 Unload the HPLC-Chip
2 Press the cover release button once. When the lock opens, pull the front
panel down.
3 Unlock the stages assembly and flip it out.
4 Remove the capillary cover (A) and open the thumb screw of the strain
relief (B). See Figure 50.
5 Loosen the slotted PEEK fitting using the Cube wrench and pull the
capillary out. See Figure 51.
Do this procedure only if the Q-TOF LC/MS is mounted on the MS or is sitting flat on
a table because the center of gravity shifts, and the instrument will tip over without
adequate support.
Figure 50 Stages assembly
