EDIT SAMPLE
S3200XL Operator’s Manual - Version 1.00 Page 133
Moving the cursor to the field and adjusting that will give you a display such as:
As with the field, you may move the cursor around the numeric field using the +/< and
-/> keys found on the numeric keypad. Running across the top of the waveform display you will
see up to four horizontal lines which show you where you have set your loop point(s). Up to
four may be shown simultaneously - the top one is LOOP 1, the second one down is LOOP 2,
the next one down LOOP3 and the bottom one is LOOP 4. I.e:
LOOP1 LOOP2 LOOP3 LOOP4
The loop points cannot be edited in the TRIM page but these will give you a clearer indication
of where you are when setting start and end points for trimming. If you move the start or end
points into a loop, you will see this screen:
A similar screen would be shown if you were to move the end point into a loop. The warning will
be shown temporarily and you should move the start (or end) point out of the loop.
Once you have set the start and end points, press F8 - - to discard the unwanted audio
either side of the start and end point. You will receive this screen display:
