EFFECTS EDIT
S3200XL Operator’s Manual - Version 1.00 Page 199
EFFECTS OUTPUT SECTION
The multi-effects section is laid out thus:
DIST/EQ MOD FX DELAY REVERB
PANLVL
PANLVL
PAN
LVL
L/R OUT
You have control over the distortion/EQ section’s level and pan, the modulation/echo
section’s output level and pan/balance and the reverb section’s output level and pan/balance.
These are made available on the FX PATH & OUTPUT page:
sets the output level for the sections denoted to the left of the fields and sets the pan
position/balance of these effects. The (width) control sets the ‘stereoness’ of the
MOD/ECHO effects. 00 sets that the effects will be mono (i.e. the left and right channel will be
summed as a mono signal) and 99 sets that the output of this effects section will be stereo.
NOTE: The control can be useful when you want to use a chorus type effect but don’t
want a wide stereo image. For example, you may wish to add chorus to a bass sound but you
may not want this sound to spread over the stereo image and dominate the mix. In this case,
set to 00 - this will give you the full effect of the chorus but will ‘monofy’ the effect so that it
doesn’t occupy a wide image in the stereo mix.
