EFFECTS
Page 162 S3200XL Operator’s Manual - Version 1.00
EFFECTS MODE
The EFFECTS key gives access to the S3200XL’s internal effects. The S3200XL’s effects
processor is a 4 channel effects processor. Two channels (FX1 and FX2) offer multi effects that
include distortion, ring modulation, EQ, modulation effects such as flanging, chorus and
phasing, stereo pitch shift, autopanning, rotary speaker simulations plus delay/echo and
reverb. The other two channels are reverb only channels (RV3 and RV4) giving a total of four
reverbs.
DISTORTION EQ RING MOD
CHORUS
FLANGE
PHASE
PITCH SHIFT
PAN/FMOD
DELAY REVERB
MOD/DELAY EFFECTS REVERB (RV1)DISTORTION/EQ
MULTI-EFFECTS CHANNEL FX1
REVERB
REVERB
REVERB ONLY CHANNEL RV3
4-CHANNEL EFFECTS PROCESSOR
or
or
or
or
DISTORTION EQ RING MOD
CHORUS
FLANGE
PHASE
PITCH SHIFT
PAN/FMOD
DELAY REVERB
MOD/DELAY EFFECTS REVERB (RV2)DISTORTION/EQ
MULTI-EFFECTS CHANNEL FX2
or
or
or
or
REVERB
REVERB
REVERB ONLY CHANNEL RV4
