1 Publication 1756-UM050A-EN-P - December 2001
Chapter
5
Using Rack Optimized I/O
About the Example
Application
This example uses rack optimized connections to read data from a
remote digital input module and send data to a remote digital output
module.
What you will do See page
Set Up the Hardware 5-2
Create the Example Application 5-3
Add the Local Ethernet Bridge to the I/O Configuration 5-4
Add the Remote Ethernet Bridge to the I/O Configuration 5-6
Add the Remote I/O Modules to the I/O Configuration 5-8
Add the Remote Digital Input Module 5-8
Add the Remote Digital Output Module 5-10
Edit the Controller Tags 5-12
Create the Ladder Program 5-14
Download the Program to the Controller 5-15
Test the Example Application 5-16
