4-10 Configuring the 1756-ENBT Module
Using a Third Party
BootP Server
The 1756-ENBT module factory default is BootP enabled. The
following is an example BootP tab file that can be used with a third
party BootP server:
# Example /etc./bootptab: database for bootp server (/etc./bootpd).
#
# Format:
# nodename:tag=value:tag=value: . . . .:tag=value
#
#first field – – nodename (hostname) of terminal followed by colon
# (should be full domain name)
#
# Blank lines and lines beginning with ’#’ are ignored.
# Make sure you include a colon and a backslash to continue a line.
# Don’t put any spaces in the tag–value string.
# The ht tag MUST precede the ha tag.
#
# The options below are specified as tag=value and delimited by colons
# These are the options used by the 1756-ENBT module:
#
#gw – – gateway IP address
#ha – – hardware address (link level address) (hex)
#ht – – hardware type (either) (must precede the ha tag)
#ip – – IP address
#sm – – network subnet mask
#tc – – template for common defaults (should be the first option listed)
#
#vm – – vendor magic cookie selector (MUST be rfc1048 for
1756-ENBT)
#
#-––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
# default values for 1756-ENBT
icp.defaults:\
ht=ether:\
vm=rfc1048:\
sm=255.255.254.0:\
gw=130.151.132.1
#-––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
zappa0:\
tc=icp.defaults:\
ha=0000bc03404f:\
ip=130.151.132.121
zappa1:\
tc=icp.defaults:\
ha=0000bc034073:\
ip=130.151.132.122
EXAMPLE
