1 Publication 1756-UM050A-EN-P - December 2001
Chapter
6
Using Analog I/O with Direct Connection
About the Example
Application
In this example you add an analog output module to the remote
chassis containing the 1756-ENBT module and the two digital I/O
modules configured in the previous chapter. Analog modules default
to direct connection. Note that you will open a direct connection to
the analog module while still using a single rack optimized connection
for the two digital I/O modules.
To test the connection the RSLogix 5000 project of the previous
chapter is modified to produce a varying signal at one of the analog
output channels.
What you will do See page
Set Up the Hardware 6-2
Create the Example Application 6-3
Add the Remote Analog I/O Module to the I/O Configuration 6-4
Edit the Controller Tags 6-8
Modify the Ladder Program 6-10
Download the Program 6-11
Test the Example Application 6-12
