1 Publication 1756-UM050A-EN-P - December 2001
Chapter
8
Interfacing with FLEX I/O
About the Example
Application
In this example the ControlLogix processor communicates with FLEX
I/O via a 1756-ENBT module and a 1794-AENT FLEX I/O adapter
using a rack optimized connection. The processor reads data from a
digital input module and sends data to a digital output module.
What you will do See page
Set Up the Hardware 8-2
Create the Example Application 8-3
Configure the I/O 8-4
Add the Local EtherNet/IP Bridge to the I/O Configuration 8-4
Add the FLEX I/O Adapter to the I/O Configuration 8-6
Add the FLEX I/O Modules to the I/O Configuration 8-8
Add the Digital Input Module 8-8
Add the Digital Output Module 8-10
Edit the Controller Tags 8-12
Create the Ladder Program 8-13
Download the Program to the Controller 8-14
Test the Example Application 8-15
