Publication 1756-UM050A-EN-P - December 2001
Interfacing with FLEX I/O 8-3
Create the Example
Application
Perform the following steps to create the example application:
1. Start RSLogix5000. The RSLogix 5000 Main Window will open.
2. From the File menu, select New. The New Controller pop-up
window will open.
3. Enter an appropriate Name for the Controller, e.g.,
“FLEX_IO_Controller.”
4. Select the correct Chassis Type and Slot number of the Logix5550
controller, and the folder where you want to save the RSLogix 5000
file (Create In). The Description is optional.
5. Click on OK.
