1 Publication 1756-UM050A-EN-P - December 2001
Chapter
7
Using Produced and Consumed Tags
About the Example
Application
In this example one Logix5550 controller (the producer) sends data to
another Logix5550 controller (the consumer) over the EtherNet/IP
network. A Timer provides the test data for the message.
What you will do See page
Set Up the Hardware 7-2
Create the Producer Application 7-3
Create the Producer Tags 7-4
Create the Producer Ladder Program 7-6
Download the Producer Application 7-7
Create the Consumer Application 7-8
Create the Consumer Controller 7-8
Add the Producer to the Consumer’s I/O Configuration 7-9
Add the Local Ethernet Bridge to the I/O Configuration 7-9
Add the Remote Ethernet Bridge to the I/O Configuration 7-11
Add the Remote (Producer) Controller to the I/O Configuration 7-13
Create the Consumer Tags 7-15
Download the Configuration to the Consumer 7-18
Test the Messaging 7-19
