Display Description Cause/Corrective Action
ECXX
Payment System Error The control communicates with the Payment System in order to per-
form vending transactions. If an error should occur, which, termi-
nates communication during a transaction, the LED Display will
show ECXX for a control generated error, where the XX represents
an error code.
E id oUtPUt
Input/Output Board ID Error The control detects the wrong output board is connected for the ma-
chine configuration. The control sounds an alarm tone for 15 sec-
onds. To clear the error, replace with the correct board.
E id drivE
Drive Board ID Error The control detects the wrong drive board is connected for the ma-
chine configuration. The control sounds an alarm tone for 15 sec-
onds. To clear the error, replace with the correct board.
ALArn
Break-in Alarm Error Check the service door and coin vault switches.
oFF
Break-in Alarm Shutdown Error Check the service door and coin vault switches.
E dS
Brownout/Voltage Configuration Unexpected supply voltage. Check the harness connections be-
tween the user control and the output board. If the user control was
replaced, set dip switch #1 to the same setting as the previous con-
trol. If reworking the machine to use a different voltage supply, the
dip switch #1 setting may need to be changed. If the dip switch #1
setting is changed, power down, power up and try again.
Coin Error
Coin Error Invalid coin pulse or inoperative coin sensor. Check coin drop area
and remove obstructions. If error persists, tampering may have oc-
curred. Evaluate security procedures.
E nr
Input/Output Board Not Ready Indicates an input/output board communication error.
The control sounds an alarm tone for 15 seconds.
To clear the error, disconnect and then reconnect power to the ma-
chine.
EnXX
Machine ID Chip Errors Communication failure. Power down, power up and try again. If er-
ror persists, check connection between user control and Machine ID
Chip, or replace the user control or the Machine ID Chip.
Right most decimal
point blinking
Machine ID Error Machine ID is no longer communicating with the control. Check
Machine ID connection.
E Co
Input/Output Board Communication
Error
Communication failure. Power down, power up and try again. If er-
ror persists, check connection between user control and input/output
board, or try replacing the user control or the input/output board.
E d Co
Drive Board Communication Error After 3 unsuccessful communication attempts, the control will turn
the drive power contactor off for 5 minutes to reset the drive. This
procedure will be executed up to 3 times before the drive communi-
cation error appears. The control enters Door Unlocking Mode after
basket rotation has stopped.
The control sounds an alarm tone for 15 seconds.
To clear the error, disconnect and then reconnect power to the ma-
chine.
Table 37 continues...
Error Codes
©
