Display Description Cause/Corrective Action
E Ld
Water Leak Drain Error (right most
decimal point)
Error will display if there is a leak after the door is opened at the
End of Cycle for 1 minute. Clears after 1 minute or until a key is
pressed. If the water level has dropped more than an acceptable
amount in a during a water leak drain check, the control will save a
water leak drain error status and will continue the machine cycle.
Immediately upon detecting the error the right-most decimal point
will be lit. This lit decimal point can be cleared by pressing the
START (enter) keypad 3 times in a period of 5 seconds or by cy-
cling the power to the machine.
E LF
Water Leak Fill Error (right most
decimal point)
If the water level has raised more than an acceptable amount in a
during a water leak check, the control will save a water leak error
status and will continue the machine cycle. Immediately upon de-
tecting the error the right-most decimal point will be lit. This lit dec-
imal point can be cleared by pressing the START (enter) keypad 3
times in a period of 5 seconds or by cycling the power to the ma-
chine.
Right most decimal
point Lit
Water Leak (Fill or Drain) Detection
or Slow Drain Detection Error
Water leak test has detected a water leak during a cycle or slow
drain is detected in the drain step of a running cycle. The decimal
point will remain lit after the error display has expired. Clear the
decimal point by pressing the START (enter) keypad three (3) times
within five seconds (5) or by cycling the power to the machine.
E bELt
Broken Belt Error After basket rotation has ended, the machine’s door unlocks.
The control sounds an alarm tone for 15 seconds.
To clear this error either power down the machine or simultaneous-
ly press the Normal and Warm keypads.
E dL
Door Lock Fatal Error The output board reports that the door unlocks while running a cy-
cle.
The control sounds an alarm tone for 15 seconds.
To clear the error, disconnect and then reconnect power to the ma-
chine.
E dL1
Door Lock Non-Fatal Error The door fails to lock after an attempt. The output board attempts to
lock the door for 70 seconds. If the door fails to lock, the machine
returns to start mode Start Mode.
E dL2
Door Unlock Non-Fatal Error If the door fails to unlock. The output board attempts to lock the
door 2 more times. If the door does not unlock, the control will flash
the START (enter) LED. If the START (enter) keypad is pressed,
unlocking attempts will restart.
E door
Door Opened During A Running Cy-
cle
Control detects door open and door locked inputs high. Can be
caused by pulling on door while locked or about to lock. Correct in-
operative door locking system. Power down machine to clear error.
