Programming the Extract Drain (Spin) Step Type
The Extract Drain (Spin) Step Type allows the owner to program
the extract drain (spin) steps of a cycle. After selecting the de-
sired Cycle Step number and pressing START (enter), XXSPin
will appear in the display. Press the Delicates Bulky (∧) or the
Cold (∨) keypad to scroll through the options and START (enter)
to select a value.
NOTE: To go back to the current programmable option
without changing the value of the active digit, press the
Warm (<) keypad.
Step
Type Display A Display B Values Description
XXSPin Spin Step Type (XX is step number, step type is flash-
ing)
En diS XXSP01 EnAbLe/diSAbL/dNod 1/
dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming Menu CNP-.
StAtUS XXSP02 PrEWSH/WASH/rinSE1/
rinSE2/rinSE3/rinSE4/
SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXSP03
0-9 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
SECond XXSP04
0-59 Step Seconds: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
drAin1 on/oFF
Drain #1
drAin2 on/oFF
Drain #2
SPEEd XXSP08 vE LoW/LoW/NEd/HigH/vE
Hi/UL Hi/XX-XXX RPM
(2.50-200.00 G Force)
Spin Speed: Very Low speed, Low speed, Medium
speed, High speed, Very High speed, Ultra High
speed or custom speed in RPM/G Force (If program-
med greater then the machine model allows, the
control will automatically limit the speed to the al-
lowed limit)
• 92-818 for 20 pound
• 86-766 for 30 pound
• 82-731 for 40 pound
• 77-685 for 60 pound
• 70-625 for 80 pound
• 70-625 for 100 pound
oUtP 1 XXSP09 on/oFF
External Output #1
oUtP 2 XXSP10 on/oFF
External Output #2
oUtP 3 XXSP11 on/oFF
External Output #3
oUtP 4 XXSP12 on/oFF
External Output #4
Table 23
High spins will extract soap and water out of the load but can al-
so produce suds that are harder to eliminate. For this reason all
spin steps consist of a step ramped spin to reduce suds genera-
tion.
