IE340 Series Installation Guide
126
Physical Specifications
Dimensions
Weights
Ventilation
Cabinet (Enclosure) Dimensions
Table 12. Product Dimensions (W x H x D)
IE340 switches 9.1 x 15.3 x 13.9 cm
(3.58 x 6.02 x 5.47 in.)
Table 13. Product Weights
IE340 switch with DIN rail bracket 2.34 kg (5.16 lbs)
IE340 switch with wall brackets 2.23 kg (4.91 lbs)
Table 14. Ventilation Requirements for Cabinet Installation
Minimum Open Space Below Switch 5.08 cm (2.0 in)
Minimum Open Space Above Switch 5.08 cm (2.0 in)
Minimum Open Space in Front of Switch 5.08 cm (2.0 in)
Minimum Open Space On Sides of Switch 5.08 cm (2.0 in)
Table 15. Minimum Cabinet (Enclosure) Dimensions
Minimum Cabinet Dimensions
(W x H x D)
50.8 x 50.8 x 30.5 cm
(20.0 x 20.0 x 12.0 in)
TBD
