Chapter 1: Overview
23
Figure 6 identifies the components on the top panel of the IE340-12GT
switch.
Figure 6. Top Panel of the IE340-12GT Switch
Back Panel Figure 7 identifies the components on the back panel.
Figure 7. Back Panel
PWR 2 DC
power connector
PWR 1 DC
power connector
Alarm In connector
Alarm Out connector
Grounding screw
DIN rail
bracket
Screw hole for
wall bracket
Screw hole for
wall bracket
Screw hole for
wall bracket
Screw hole for
wall bracket
