Allied Telesis IE340 Series Installation Guide

Chapter 1: Overview
43
LEDs
The following sections describe the LEDs on the switches:
 “Status LEDs” , next
 “Twisted Pair Port LEDs on PoE PSE Switches” on page 45
 “Twisted Pair Port LEDs on the IE340-12GT Switch” on page 46
 “SFP Slot LEDs” on page 47
Status LEDs The status LEDs are defined in Table 4.
Table 4. Status LEDs
LED State Description
Fault
Off The switch is operating normally or powered
off.
Solid Amber The switch is booting up.
Five flashes
followed by
a pause
The switch is experiencing an alarm
condition. Use the SHOW FACILITY-
ALARM STATUS command to view active
alarms. The ALARM FACILITY command in
the Global Configuration mode is the
command for programming the Fault LED to
flash in response to an alarm condition. The
following example of the command
configures the switch to flash the Fault LED
if port 1 does not have a link to a network
device:
alarm facility link-down
port1.0.1 led
For more information, refer to the Software
Reference for IE340 Series Switches or
Command Reference for IE340 Series
Switches.
Six flashes
in two
seconds
The switch is overheating and might
shutdown.
