Allied Telesis IE340 Series Installation Guide

Chapter 1: Overview
47
SFP Slot LEDs Each SFP slot has one LED. For the IE340-12GP, IE340-12GT, and
IE340-20GP switches, see Table 7. For the IE340L-18GP switch, see
Table 8 on page 48.
Table 6. Twisted Pair Port LEDs on the IE340-12GT Switch
LED State Description
Duplex
Mode
Solid Green The port is operating in full duplex mode.
Solid Amber The port is operating in half duplex mode.
Off The port has not established a link with a
network device.
L/A
Solid Green The port has established a 1000 Mbps link to a
network device.
Flashing
Green
The port is transmitting or receiving data at
1000 Mbps.
Solid Amber The port has established a 10 or 100 Mbps link
to a network device.
Flashing
Amber
The port is transmitting or receiving data at 10
or 100 Mbps.
Off The port has not established a link with another
network device.
Table 7. SFP Slot LED for the IE340-20GP, IE340-12GP, and IE340-
12GT Models
State Description
Solid Green The port has established a 1Gbps link to a network
device.
Flashing Green The port is transmitting or receiving network packet
traffic at 1Gbps.
Solid Amber The port has established a 100Mbps link to a
network device.
Flashing Amber The port is transmitting or receiving network packet
traffic at 100Mbps.
Off The port has not established a link to a network
device.
