Operating
148
Operating
0000010038-003- GB
The DUPLEX mitre fence can be infinitely adjusted from 0° to 90°. The circular
scale with a radius of 350 mm has 0.25° graduation, allowing precise and fast
setting of the mitre angle. The DUPLEX mitre fence can be fitted at any position
of the sliding table due to its eccentric clamping system.
The stop bar (2 throw-over stops) can be used in both stop profiles. It is possib-
le to crosscut workpieces of up to 1350 mm in length or, when the extended
stop fence is used, up to 2150 mm in length.
In addition, the DUPLEX and DUPLEX D mitre fence features a length com-
pensation scale with which the length dimension is set in accordance with the
mitre angle.
i
Note!
Separate instructions are enclosed for the selected options DUP-
LEX, DUPLEX D or DUPLEX DD.
