Operating
102
Operating
0000010038-003- GB
6.3.4 Fitting the main saw blade
AKE clamping system
Warning!
The following points must always be observed:
Non-adherence may lead to severe injuries!
• Do not fit any saw blades that are cracked or damaged in any way.
• Only fit saw blades with a diameter between 250 and 550 mm.
Machines with a scoring unit have a maximum saw blade diameter of
only 500 mm!
• The maximum rotational speed n max stated on the tool must not be
exceeded.
Fig. 6-25 Front flange
Fig. 6-26 Lock on the middle carriage
