Operating
121
0000010038-003- GB
Operating
6.4.7 RAPIDO Plus scoring saw
RAPIDO Plus is a 3-axis scoring system with motorised adjustment of the cut-
ting height and the right and left-hand side of the scoring saw blade. All settings
can be made while the machine is running, so they can be done very quickly.
Press the axis selection button for the scorer; the following display appears:
Button 1 <> Back to previous page
Button 2 <> Cutting height adjustment
Button 3 <> Position of right saw blade side
Button 4 <> Position of left saw blade side
Button 5 <> Reference
Fig. 6-43 Selection button for scorer adjustment
Fig. 6-44 Adjusting the scorer
