Technical data
200
Technical data
0000010038-003- GB
9 Technical data
9.1 Standard equipment
Saw blade heights: Standard up to 450 mm
Features
Electromotive height and tilt adjustment 0 - 46 ° for the main saw blade, for til-
ting in both directions from -46° to +46°,
with automatic correction of the cutting height when tilting the saw unit, and with dis-
play of tilt angle and cutting height.
F45 display control system with dimension input via the keypad
Saving of 99 programs
Sliding table incl. infinitely variable top carriage locking
Sliding table length 3000 mm
Rip fence
Cutting width 1000 mm, table width extension, aluminium anodised
• Manual adjustment with precision setting
Crosscut fence
• manual adjustment, crosscutting up to 3200 mm, 2 operating positions on the
cross-slide frame
Drive power / rotational speed of main saw shaft
With automatic brake and display of rotational speed
• 4kW (5.5 PS) with a rotational speed of 4000 rpm
Tool clamping system AKE
for main saw blade
Max. cutting height 150 mm, max. saw blade diameter 450 mm
Cutting heights: see table
Table length extension
840 mm, aluminium anodised
USB-A port for data and program transfer
Machine diagnosis and operating hours meter
Aluminium parts in anodised finish
Clamping shoe, push stick, push block handle and pull-back handle
