Technical data
204
Technical data
0000010038-003- GB
9.2 Special equipment
Available special equipment
Main saw drive
Heavy-duty motors up to 11 kW (for machines tilting to one side)
Infinite rotational speed adjustment (VARIO, adjustable in increments of 5, power for
machines tilting to one side: 5.5kW, 7.5kW , power for machines tilting to both sides:
5kW and 6.5 kW)
Sliding table
Sliding table lengths from 2250 mm to 5000 mm
Second support (STEG), support width extension by 400 mm
On/Off switch at the end of the sliding table
Crosscut-mitre fence
Length dimension adjustable via digital display with fine adjustment (DIGIT L), set-
ting accuracy 0.1 mm, crosscutting up to 3200 mm
Length dimension, angle, length compensation via digital display (DIGIT LD), setting
accuracy 0.1 mm / 0.1°, crosscutting up to 3200 mm
Mitre fences
One-sided mitre fence, angle adjustable via scale from - 30° to 45°, crosscutting up
to 2500 mm
Double-sided mitre fence (DUPLEX), angle adjustable via scale from 0° to 90°, cros-
scutting up to 1350 mm or 2150 mm, length compensation
Double-sided mitre fence (DUPLEX D), angle digitally adjustable, setting accuracy
0.01°, crosscutting up to 1350 mm or 2150 mm, length compensation
Double-sided mitre fence (DUPLEX DD), angle and length digitally adjustable, set-
ting accuracy 0.01° / 0.1 mm, length display is adapted automatically in accordance
with the angle that is set, crosscutting up to 1350 mm or 2150 mm
Rip fence
With digital dimension display and fine adjustment, setting accuracy 0.1 mm
Parallel cutting device
Parallel cutting device (PALIN), crosscutting up to 900 mm, adjustable via scale
Parallel cutting device (PALIN_D), crosscutting up to 900 mm, digitally adjustable,
setting accuracy 0.1 mm
