Operating
1. Switch off the drive.
2. Set the saw blade to the maximum cutting height and tilt to 0°.
3. Turn off the main switch.
4. Move the top carriage to the middle of the saw shaft, and unlock the lock at
the saw blade centre by pressing the knob on the middle carriage.
5. Move the top carriage to the end position in the cutting direction.
6. Raise the red cover plate.
7. Use the wrench to release the screw in the expansion-head screw.
8. Undo the expansion-head screw by turning it counterclockwise with the
flange.
9. Before fitting the new saw blade, remove any adhering chips and dust from
both flanges.
10. Place the saw blade and front flange onto the saw shaft, turn in the expan-
sion-head screw by hand and tighten it with the wrench.
11. Check the riving knife for strength and distance from the saw blade.
12. Close the red protective cover and perform a short test run to see whether
the saw blade is running freely. Do this by lowering the top protection hood
down to the table so that the saw blade is completely covered.
Warning!
Check that saw blade clamping system is tight before operating the
machine!
