Technical data
202
Technical data
0000010038-003- GB
Technical data:
Main saw Tool holder diameter
Saw blade tilting range
Idling speed
Tool edge width
30 mm
0-46°
4000 rpm
max.20 mm
Sliding table Sliding table cutting length See table
Crosscut fence Crosscutting at 90° crosscut fence 3200 mm
Rip fence Cutting width at rip fence 1000
Extraction Connection socket diameter below table
Connection socket diameter at top safety hood
Overall vacuum connection ∅ 140 mm
Air speed
Minimum air volume
120 mm
80 mm
1200 PA
20 m/s
1110 m
3
/h
Ambient conditions Operating temperature
Max. relative humidity
Do not expose the machine to a gaseous
environment which is explosive or may
cause corrosion!
10 - 40 °C
90 %, no condensation
