Transport, siting and installation
46
Transport, siting and installation
0000010038-003- GB
Installing the telescopic tube, 4th axis
Fig. 5-4 Swivelling arm, 4th axis
[1] Support bolt
[2] Plug-type connection plate, telescopic tube
[3] Plug-type connection plate, swivelling arm housing
i
Note!
• The two plug-type connections have a different number of pins!
• The number of pins is 3 and 5.
• The 5-pole connection is marked red!
Fig. 5-5 Plug-type connections
